1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180
1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180
1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180

1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180

Product Details:

  • Structure Single Stage Pump
  • Power Electric
  • Suction Type Immersion
  • Click to View more
X

1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 Price And Quantity

1/8 HP Machine Coolant Pump 180mm (7inch) Lathe Grinding Mill Saw Drilling Machinery TC-8180 Product Specifications

  • Immersion
  • Single Stage Pump
  • Electric

Product Description

The TC Series coolant pump is developed for spraying of cooling lubricants and the circulation system, especially for machine tools. It is suitable to driver liquids such as water, coolant, light oil and other clean, non-aggressive matters liquid to cooling or lubricant applications. TC Series can be used in all type machine tools to perform Turning, Milling, Drilling, Cutting, Slitting, Grinding etc. operation (Lathing machine drilling machine, lapping machine, Milling machine, pressing machine, stamping machine, tapping machine, punch machine, cooling system, oil cooling, water circulation)

Product Features :

- Powerful and high-performance coolant liquid pump

- Whole models with efficient filterable strainer.

- Solid entire unit and high stability & reliability.

- Well design to dissipate thermal- CE & IP54 with utility patents


Product Specification :

  • Brand: YU HSENG
  • Model: TC-8180
  • Power: 94W (1/8 HP )
  • Phase & Voltage ( Low Volt / High Volt ) Options:
  • 1 Phase& 100/200V, 110/220V, 120/240V
  • 3 Phase & 208/415V, 220/380V, 220/440V, 230/460V, 240/480V, 575V
  • (Manufacture default wire in high )
  • Discharge Bore: NPT  3/8 ", NPT 1/2", PT 3/8", PT 1/2" (PT=BSPT=Rc)
  • Length (flange to bottom): 180mm (7 ").

 - Flow rate in 60 Hz:

  •   1 Phase, 3/8"  : 9.2   GPM (35 L/min );
  •   3 Phase, 3/8"  : 9.8   GPM (37 L/min );
  •   1 Phase, 1/2"  : 10.6 GPM (40 L/min );
  •   3 Phase, 1/2"  : 11    GPM (42 L/min );
- Lift (Head Height) in 60 Hz :
  •   1 Phase, 3/8"  : 5.4 M;
  •   3 Phase, 3/8"  : 6.0 M;
  •   1 Phase, 1/2"  : 5.2 M;
  •   3 Phase, 1/2"  : 5.7 M;
- Pressure in 60 Hz :
  •   1 Phase, 3/8"  : 7.7 PSI;
  •   3 Phase, 3/8"  : 8.5 PSI;
  •   1 Phase, 1/2"  : 7.4 PSI;
  •   3 Phase, 1/2"  : 8.1 PSI;


# For Voltage in 50 Hz, please values multiply *0.84#

HP

Discharge Bore

Flow Rate (L/min)

Pressure (Meter of Head)

Weight

1 Phase

3 Phase

1 Phase

3 Phase

(Kg)

1/8

3/8"

35

37

5.4

6

3.3

1/2"

40

42

5.2

5.7

3.3

- Made in Taiwan
